ARRI M8 Tageslicht Scheinwerfer
Product information "ARRI M8 Tageslicht Scheinwerfer"
The ARRI M8 is the latest and smallest addition to ARRI’s highly successful M-Series of HMI lampheads. Equipped with the unique, patented MAX Technology, the M8 combines the advantages of both Fresnel and PAR fixtures in one unit.
Thanks to its open-face design and the unparalleled efficiency of the MAX Technology reflector, the M8 is exceptionally bright. The light output produced by its 800 W lamp is remarkably close to that of a 1,200 W Fresnel or PAR fixture (with lens). The unit can be easily focused between 15° and 60° by simply turning the focus knob, creating a remarkably even light field and a crisp, clear shadow. By eliminating the need for bulky, easily breakable spread lenses, the M8 significantly speeds up workflows on set.
Key Features:
- Lens-less MAX Technology: Easy to use and quick adjustments.
- Light output comparable to 1,200 W fixture: Impressive brightness with lower power consumption.
- Smallest lamphead with MAX Technology reflector: Compact and powerful.
- Highly mobile: Versatile for a wide range of applications.
- Focusable between 15° and 60°: Precise light shaping.
- Cross-Cooling: Safe operation even at 90° tilt.
- Compatible with existing accessories: Uses 230 & 245 mm accessories from ARRI True Blue D12 and Chimera.
- Compensation for Cable Losses (CCL): Reliable performance.
- Uses existing 575 to 1,800 W cables: Flexible cabling options.
- Suitable for high frame rate images: Ideal for modern productions.
- IP Rating IP23: Robust and durable.
- Tilt locks: Holds heavy accessories stable.
Technical Data:
- Series: M-Series
- Model: M-Series M8
- Mains Plug: VEAM
- Lamphead Type: Open Face with Facetted Reflector, 800 W
- Reflector: MAX Technology reflector made of high purity aluminium
- Lamp Type: Metal Halide 800 W/SE (Only 800 W, no 575 W lamps)
- Power Consumption: 800 W
- Voltage Range: 90 to 130 V / 180 to 250 V
- Lamp Base: G22
- Dimming: Yes, 50 to 100 % via ARRI Ballast Unit
- Correlated Color Temperature: 6,000 K
- Beam Angle: 15° to 62°
- Weight in kg net (approx.): 8.5 kg
- Weight in kg packed (approx.): 10.7 kg
- Weight in lbs. net (approx.): 18.50 lbs
- Weight in lbs. Packed (approx.): 23.50 lbs
- Measurements (HxWxL) incl. Pin (approx.): 591 x 350 x 310 mm
- Measurements (HxWxL) excl. Pin (approx.): 458 x 350 x 310 mm
- Measurements (HxWxL) Packed size (approx.): 440 x 400 x 460 mm
- Lens / UV-Protection Glass Diameter: 200 mm
- Accessory Diameter: 230 mm (Scrim)
- Barndoor: 245 mm
- Mounting: Spigot 28 mm / 1 1/8" (1.1")
- Housing Color: Blue/Silver
- Protection Class / IP Rating: I / IP23
- Certifications: CE, UKCA, CB, ENEC, cNRTLus
| Beam Angle: | 15° - 62° |
|---|---|
| Certifications: | CB, CE, GS, cNRTLus |
| Colour temperature: | 6000 K |
| Connection: | VEAM |
| Dimming: | 50 - 100% via ARRI Ballast Unit |
| Housing Color: | blue/silver |
| Lamp Base: | G22 |
| Lamp Type: | Metal Halide 800 W/SE |
| Light Engine: | Discharge lamp |
| Mains Plug: | VEAM |
| Operation: | MAN |
| Power Consumption: | 800 W |
| Protection Class / IP Rating: | IP 23 |
| Reflector: | Open Face with Facetted Reflector |
